Main size
Overall length
15000mm

Overall width
2700mm

Overall height
3100mm

Loading capacity
Loading 8 units of cars.
Capacity of 25Tons.

Chassis
Main beam
Material of high strength steel T700.
Height 400mm.
Welded by automatic submerged-processes.

Main cross beam
Material is high strength steel T700.
Welded by automatic submerged-arc processes

Posts
Main posts
Material of high tensile steel T700.
5 pairs of each trailer

Side bars
Material is high strength steel T700.
Multi numbers installed.

Floor
Material
Manganese steel plate floor thickness of 3mm.
Multi holes designed.
Yellow and red painted track.

Landing gear
20T model landing gear, brand Yahua, with static capacity of 50T.
Single speed linked type, operated at one side.

King pin
2 inches size, installed on the kingpin plate.
JOST brand.

Axle
2 sets of 13T model axles.
Axle beam 1840mm.
Axle loading 13000kgs.

Tire
Tire sized 10R22.5, Double Star or Triangle brand.
4 sets of tires assembled with wheel rim per trailer.

Wheel rim
Sized 8.0-20, Zhengxing brand.
4 pcs of wheel rim per trailer.

Hydraulic
Cylinders
5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars.
Youggu brand.

First unit
At the front post, out&back, extend 600mm.

Second unit
At the end post of gooseneck, out&back, extend 600mm.

Third unit
Under the aircraft style plate, to lift single car, out&back, extend 900mm.

Forth unit
At the post in front of tire, out&back, extend 900mm.

Fifth unit
At the end post of trailer, only out, back by the cars' gravity, extend 1600mm.

Suspension
Mechanical steel suspension system, double axles type.
4 sets of leaf springs installed.

Brake sysem
Dual line air drum brake system with T30/30 type double brake chambers on each axle.

Light system
12v/24v light system.
LED lights, including side, rear, turning.

ABS system
ABS system installed, HN or Kemi brand.

Others
Color optional.
One set of standard tools in tool box.
One bag of belts for firming the cars.

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 0

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 1

Etiquetas:

low bed semi trailer,

semi lowbed trailer,

low bed tractor trailer

Produtos recomendados

Vídeo

2 eixos 28 toneladas Lowbed Lowboy Truck Trailer Semi-trailer para transporte de equipamentos pesados

Contacte agora

Vídeo

3 eixos dianteiros de carga de baixo leito de reboque com coluna hidráulica desmontável e ABS opcional

Contacte agora

Vídeo

Carga útil máxima 120 toneladas Tri-eixos Heavy Duty Lowbed Semi-Trailer com rampa e paredes laterais

Contacte agora

Vídeo

3-Axle 13T Car Carrier Semi Trailer with 500mm Main Beam

Contacte agora

Vídeo

Preço de Lowbed Transportador de Escavadeira Semi-Reboque Low Bed Truck Com Rampa Hidráulica Multi 3 4 5 Eixos 40 60 80 120 100 Toneladas para Venda

Contacte agora

Vídeo

Two, Three, Four Axle Gooseneck Flatbed Semi Truck with Low Deck, Lowboy, Loader, or Low Bed Semi Trailer

Contacte agora

Vídeo

Heavy-duty Customizable 3-Axis 60-120 Tons Foldable Construction Machinery Transportation Low-bed Trailer Trailer Truck

Contacte agora

Detalhes dos produtos

produtos

Semi-reboque de cama baixa

Semi-reboque de contentor

Reboque da parede lateral semi

Semi-reboque de transporte de veículos

Semi-reboque de descarga/derrapagem

Semi-reboque lateral Van&Curtain

Cerca Semi Trailer

Semi-reboque para transporte de animais

do petroleiro reboque semi

Reboque agrícola e outro reboque completo

Carrinho de lixo Howo

cabeça do trator

Trailer especial

Peças sobressalentes de reboque

Veículos novos da energia

Veículos especiais

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS

Quantidade mínima:	1 unidade
embalagem padrão:	Padrão de exportação
Período de entrega:	25 dias
método de pagamento:	T/T.

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem

China

Marca

AOTONG

Certificação

ISO,CCC

suspensão:

Suspensão mecânica ou aérea

Especificações dos pneus:

12R22.5

Feixe principal:

Pesado eu raio.

Pino de parentes:

2 '' '/3.5' 'Tipo de parafuso

Sistema de frenagem:

Câmara de ar dupla, válvula de freio, tanques de ar 45L; abdom

Elétrica:

Luz LED, 7 maneiras, 24V

Pintura:

Explosão e ferrugem limpa, 1 camada de pintura primitiva, 2 camada de pintura de acabamento

Quantidade de ordem mínima:

1 unidade

Detalhes da embalagem:

Padrão de exportação

Tempo de entrega:

25 dias

Termos de pagamento:

T/T.

Destacar

2-axle car carrier trailer with ABS

lowbed semi trailer 18T-28T capacity

heavy duty car carrier trailer ABS

Descrição do produto

Main size
Overall length
15000mm

Overall width
2700mm

Overall height
3100mm

Loading capacity
Loading 8 units of cars.
Capacity of 25Tons.

Chassis
Main beam
Material of high strength steel T700.
Height 400mm.
Welded by automatic submerged-processes.

Main cross beam
Material is high strength steel T700.
Welded by automatic submerged-arc processes

Posts
Main posts
Material of high tensile steel T700.
5 pairs of each trailer

Side bars
Material is high strength steel T700.
Multi numbers installed.

Floor
Material
Manganese steel plate floor thickness of 3mm.
Multi holes designed.
Yellow and red painted track.

Landing gear
20T model landing gear, brand Yahua, with static capacity of 50T.
Single speed linked type, operated at one side.

King pin
2 inches size, installed on the kingpin plate.
JOST brand.

Axle
2 sets of 13T model axles.
Axle beam 1840mm.
Axle loading 13000kgs.

Tire
Tire sized 10R22.5, Double Star or Triangle brand.
4 sets of tires assembled with wheel rim per trailer.

Wheel rim
Sized 8.0-20, Zhengxing brand.
4 pcs of wheel rim per trailer.

Hydraulic
Cylinders
5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars.
Youggu brand.

First unit
At the front post, out&back, extend 600mm.

Second unit
At the end post of gooseneck, out&back, extend 600mm.

Third unit
Under the aircraft style plate, to lift single car, out&back, extend 900mm.

Forth unit
At the post in front of tire, out&back, extend 900mm.

Fifth unit
At the end post of trailer, only out, back by the cars' gravity, extend 1600mm.

Suspension
Mechanical steel suspension system, double axles type.
4 sets of leaf springs installed.

Brake sysem
Dual line air drum brake system with T30/30 type double brake chambers on each axle.

Light system
12v/24v light system.
LED lights, including side, rear, turning.

ABS system
ABS system installed, HN or Kemi brand.

Others
Color optional.
One set of standard tools in tool box.
One bag of belts for firming the cars.

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 0

2-Axle Car Carrier Trailer 18T-28T Capacity with ABS 1

Etiquetas:

Main size	Overall length	15000mm
	Overall width	2700mm
	Overall height	3100mm
	Loading capacity	Loading 8 units of cars. Capacity of 25Tons.
Chassis	Main beam	Material of high strength steel T700. Height 400mm. Welded by automatic submerged-processes.
Chassis	Main cross beam	Material is high strength steel T700. Welded by automatic submerged-arc processes
Posts	Main posts	Material of high tensile steel T700. 5 pairs of each trailer
Posts	Side bars	Material is high strength steel T700. Multi numbers installed.
Floor	Material	Manganese steel plate floor thickness of 3mm. Multi holes designed. Yellow and red painted track.
Landing gear	20T model landing gear, brand Yahua, with static capacity of 50T. Single speed linked type, operated at one side.
King pin	2 inches size, installed on the kingpin plate. JOST brand.
Axle	2 sets of 13T model axles. Axle beam 1840mm. Axle loading 13000kgs.
Tire	Tire sized 10R22.5, Double Star or Triangle brand. 4 sets of tires assembled with wheel rim per trailer.
Wheel rim	Sized 8.0-20, Zhengxing brand. 4 pcs of wheel rim per trailer.
Hydraulic Cylinders	5 units (2 sets of each unit) of hydraulic cylinders installed, to lift the second floor and cars. Youggu brand.
	First unit	At the front post, out&back, extend 600mm.
	Second unit	At the end post of gooseneck, out&back, extend 600mm.
	Third unit	Under the aircraft style plate, to lift single car, out&back, extend 900mm.
	Forth unit	At the post in front of tire, out&back, extend 900mm.
	Fifth unit	At the end post of trailer, only out, back by the cars' gravity, extend 1600mm.
Suspension	Mechanical steel suspension system, double axles type. 4 sets of leaf springs installed.
Brake sysem	Dual line air drum brake system with T30/30 type double brake chambers on each axle.
Light system	12v/24v light system. LED lights, including side, rear, turning.
ABS system	ABS system installed, HN or Kemi brand.
Others	Color optional. One set of standard tools in tool box. One bag of belts for firming the cars.
